Detail Information
- Price: $0.41 $0.47
- Delivery: Shipping fee: $3.29
- Rating: 0.0
Specifications
- Hign-concerned Chemical: none
- Package: integrated circuit
- is_customized: Yes
- Model Number: integrated circuit
- Operating Temperature: integrated circuit
- Dissipation Power: integrated circuit
- Supply Voltage: integrated circuit
- Application: integrated circuit
- Condition: New
- Type: cischy
- Brand Name: cischy
- Electronic Components Supplies: integrated circuit
- Electronic Components Supplies2: integrated circuit
- Electronic Components Supplies3: integrated circuit
- Electronic Components Supplies4: integrated circuit
- Electronic Components Supplies5: integrated circuit
- Electronic Components Supplies6: cischy
Introduction
The KA431AZ is a highly versatile and reliable integrated circuit (IC) that finds widespread application in electronic circuits. This exceptional product, offered in a cost-effective package of 5 pieces, is meticulously crafted to deliver superior performance and durability, making it an ideal choice for various electronic projects.
Key Features and Benefits
- High Accuracy: The KA431AZ boasts an impressive voltage reference accuracy of ±1.5%, ensuring exceptional precision in applications requiring stable voltage levels.
- Adjustable Output Voltage: Its adjustable output voltage capability provides the flexibility to customize the voltage reference to suit specific circuit requirements, ranging from 2.5V to 36V.
- Low Drift: The IC exhibits an extremely low temperature drift of typically 50ppm/°C, maintaining consistent performance over a wide operating temperature range.
- High Output Current: With a maximum output current of 100mA, the KA431AZ can drive external loads efficiently, making it suitable for a variety of applications.
- Enhanced Stability: The built-in temperature compensation circuitry ensures high stability and minimizes output voltage variations under varying operating conditions.
Applications
The KA431AZ is widely employed in a multitude of electronic applications, including:
- Voltage Regulation: It serves as a highly effective voltage regulator, providing a stable reference voltage for analog circuits.
- Power Supply Design: The IC is commonly used in power supply circuits to regulate output voltages and protect against overvoltage conditions.
- Precision Measurement: Its high accuracy makes it suitable for precision measurement applications, such as analog-to-digital converters (ADCs).
- Protection Circuits: The KA431AZ is often integrated into protection circuits to safeguard sensitive components against overvoltage and overcurrent events.
- Sensor Interfaces: It is an ideal choice for interfacing with sensors that require a precise and adjustable voltage reference.
Specifications
- Operating Temperature Range: -55°C to 125°C
- Supply Voltage Range: 3V to 37V
- Output Voltage Range: 2.5V to 36V
- Output Current: 0 to 100mA
- Voltage Reference Accuracy: ±1.5%
- Temperature Drift: Typically 50ppm/°C
- Package Type: TO-92
Frequently Asked Questions
Q: What is the primary function of the KA431AZ?A: The KA431AZ is a versatile integrated circuit that serves as a stable and adjustable voltage reference.
Q: How does it contribute to electronic circuits?A: Due to its high accuracy, adjustability, and stability, the KA431AZ enhances the performance and reliability of voltage regulation, power supply design, precision measurement, and protection circuits.
Q: What is the recommended operating temperature range for the KA431AZ?A: The KA431AZ operates effectively within a temperature range of -55°C to 125°C, ensuring reliable performance under various environmental conditions.
